Rod Choke Coils

Power Splitter Divider Product Introduction

Introducing our Power Splitter Divider series: a high-performance and versatile solution designed for RF signal distribution in telecommunications, broadcasting, satellite communication, and test equipment applications. Engineered with precision and reliability in mind, this series offers a variety of configurations and specifications to ensure optimal signal integrity and minimal loss, catering to a wide range of system requirements.

Key Features and Specifications

• Configurations and Impedance Options: Available in 2-way, 3-way, and 4-way configurations with impedance options of 50Ω and 75Ω, providing flexibility for diverse system designs.




• Wide Frequency Coverage: Supports operational bandwidths starting as low as 1 MHz and extending up to 3250 MHz (3.25 GHz), depending on the model. Examples include:


• 50Ω 2-way (B008 package): 5 MHz to 1000 MHz

• 75Ω 2-way (B004 package): 5 MHz to 3250 MHz

• 75Ω 3-way (B115 package): High-performance model with unspecified frequency range in some datasets but optimized for broad applications




• Exceptional Performance Parameters:


• Input Return Loss (RL): Ranges from 5 dB to 38 dB, ensuring efficient power transfer with minimal reflection.

• Insertion Loss (IL): Low values from 0.28 dB to 4.5 dB, minimizing signal attenuation across outputs.

• Isolation: Robust isolation between output ports, ranging from 12 dB to 35.48 dB, reducing interference and enhancing signal clarity.




• Compact and Varied Packaging: Offered in multiple package types, such as B008, B015, B032, B108, B115, and larger formats like 60x51 mm, accommodating different installation needs.

Performance Highlights

• 2-Way Splitters:


• 50Ω (B008): 5–1000 MHz, RL 16 dB, IL 0.8 dB, Isolation 18 dB

• 75Ω (B004): 5–3250 MHz, RL 12 dB, IL 0.5 dB, Isolation 12 dB

• 75Ω (B032): 40–2050 MHz, RL 20 dB, IL 0.5 dB, Isolation 25 dB






• 3-Way Splitters:


• 75Ω (B115): RL 38 dB, IL 0.28 dB, Isolation 28 dB, ideal for high-precision applications




• 4-Way Splitters:


• 50Ω (62x49.8 mm package): 5–2400 MHz, RL 15 dB, IL 4 dB, Isolation 16 dB These metrics demonstrate stable, high-quality signal distribution across a variety of frequency ranges and configurations.

Applications and Benefits

Our Power Splitter Divider series is designed for versatility, excelling in applications such as wireless base stations, CATV systems, satellite communications, and laboratory testing. Its compact design facilitates seamless integration into modern electronic systems, while its low insertion loss and high isolation ensure maximum performance. Whether you need to split signals with minimal distortion or maintain reliability across a wide frequency spectrum, this series delivers exceptional results.

Why Choose Our Power Splitter Divider?

• Reliability: Built for consistent performance and high signal integrity.

• Flexibility: Multiple configurations and impedance options to meet specific needs.

• Efficiency: Low loss and high isolation for superior signal distribution.

Elevate your RF signal management with our Power Splitter Divider series—your go-to solution for precision, performance, and adaptability in any application.
