Flat Wire Inductors
Our series of RF air core inductors are designed for high-frequency applications, offering superior performance and reliability. These inductors feature an air core design, eliminating magnetic saturation issues and ensuring stable inductance values. The surface mount (SMD) package allows for easy and efficient PCB assembly, making them ideal for automated manufacturing.
Table of Contents
Key Features
Air Core Design: Prevents magnetic saturation, ensuring stable inductance and high Q-factor.
Surface Mount Technology (SMT): Enables easy and cost-effective PCB assembly.
Flat Copper Wire Construction: Minimizes DC resistance and maximizes current handling capability.
Environmentally Friendly: RoHS compliant, ensuring adherence to environmental regulations.
Product Series
TCS1010: Inductance range: 0.023μH - 0.146μH
TCS1212: Inductance range: 0.022μH - 0.117μH
TCS2014: Inductance range: 0.033μH - 0.257μH
TCS2015: Inductance range: 0.033μH - 0.066μH
Applications
These RF air core inductors are suitable for a wide range of high-frequency applications, including:
Wireless communication systems
RF filters and matching networks
High-frequency power supplies
Instrumentation and measurement equipment
Benefits
High Q-factor and low DC resistance for optimal performance.
Stable inductance over a wide temperature range.
Compact size and surface mount design for space-saving PCB layout.
Reliable and robust construction for long-term operation.
Contact Us
For more information or to request a sample, please contact us.
